Item

Model

ME 500

ME 600

ME 800

ME 1000

ME 1200

ME 1500

Capacity

Output power

500VA/300W

600VA/360W

800VA/480W

1000VA/600W

1200VA/720W

1500VA/900W

Input

Voltage range

165~275Vac��5V (140--280v is option ) or 70 - 140V

Frequency range

50 or 60 �� 2.5Hz

Output

Voltage

220V or 110V �� 10%

Frequency

50 or60 �� 6Hz(battery mode)

Transfer time

Max:10Ms

Waveform

Simulated sine wave

Battery

Type

Sealed lead acid, maintenance free

DC voltage

12VDC

Battery number

1*12V/7AH

1*9AH/12VDC

2*12V/7AH

2*12V/7AH

2*12V/7AH

Protection point oflow Voltage

9.5VDC-12VDC

Standby time

Full load >3min,half load >8min

Recharge

After fully discharged, charge 8 hours to 90% capacity

Protecting

Output overload

Fuse & current limited when overloaded

Battery low voltage

Automatically lock out the machine so as to protect the Battery from over discharging

Short circuit

Fuse & current limited

Restart

Auto restart when AC recovery.

Alarm

Battery back-up

Sounding every about 4 seconds

Battery low

Sounding every about 1 second

Overload

Indicator

LED

LED indicator for line on, battery back-up, UPS cut-off

Surge Protection

320 Joules, RJ11, RJ45

Communication

RS232

Package size

L*W*H(mm) 2PCS

590*315*240

385*15*235

400*315*335

480*405*290

480*405*290

Package weight

Kg, 2PCS

9Kg

11Kg

13.4Kg

19.6Kg

19.6Kg
