UPS-M special for pas basstatlon

SKU: FS00019575

Reproduction is welcome and allowed for free circulation only.

General(UPS-M special for pas basstatlon)

UPS special for PAS is kind of uninterrupted power supply specially designed for PAS base station , it can output with stable voltage under commercial
power, and when the voltage of commercial poweris too high or too low ( Include power off ) , it can output AC power with inversion for a long time (10
~ 20hrs , depending on the load and battery ) to support PAS uninterrupted communication function.

ltem(UPS-M special for pas basstatlon)

1. Reserve time: 12h (Determined by load)
2. Battery capacity: 12V/38AH 2 or 12V/65AH
3. Battery type: Maintenance-free and sealed lead acid battery
4. Charge time: 12hrs (>90%)
5. Charge current: Charge as per segment, the max is 6A.
6. Continuous output power: >45W
7. Max output power: 120W
8. Power off frequency: 100 times per year
9.Life: 5 years (Assure it can discharge 30min continuously after 5 years)
10.Structure: Rainproof machine case, UPS main machine and battery (The
main machine and battery shall be put in the thieving-proof machine case.)
11. Volume: 410mm×225mm ×440mm (Designed according to rainproof structure)
12. Weight: 38KG.

Powery supply(UPS-M special for pas basstatlon)

1. Rated input voltage: 220VAC
2. Input frequency: 50HZ±5%
3. Range of input voltage: 150~275VAC
4. Output voltage: 220V±10%AC (Commercial power), 220VAC (Battery)

Technical specification(UPS-M special for pas basstatlon)

1. Working environment temperature: -20～+50℃
2. Waterproof performance: According to the standardGB4208, the protection grade is 3.
3. Protection against thunder : Lightning protectioninstalled .
4. Radiated noise: During the product running the limitof radiated interference strength conforms to requirement of GB254
5. Conducted noise：＜45dB。
6. MTBF：＞3000hrs
7. Leakage current to ground: ＜1mA
8. Electric strength : The input terminal and outputterminal to ground bear 220V / 50Hz AC voltage for1min, no flashing and arc shows.
9. Insulation resistance: When DC voltage is 500V ,resistance of input terminal and output to ground ismore than 2MΩ.

Function(UPS-M special for pas basstatlon)

1. After opening UPS, it will start to run automatically,with low battery voltage auto-shut down function,when the commercial power resumes, it will open
automatically not need people to operate.

2. Under the condition of normal commercial power,UPS has voltage regulation function, and when thecommercial power occurs fault, the battery outputsthrough voltage regulating, the switching time is less than ＜10 ms.
