Picture of Omni-directional Antenna

Omni-directional Antenna

SKU: FS00034346
Omni-directional Antenna
Reproduction is welcome and allowed for free circulation only.


Product Name 824-896GHz fiberglass antenna
Description TQJ-824/896-10D: The fiberglass antenna is designed for wireless access system. Which through optimization design and careful debugging with follow qualities: good standing wave performance,high gain,broad band,big F/B ratio,strong structure,own the good ability of antihunting,waterproof and anticorrosion; Small size,easy installation,the directional diagram will be unacted whether installate on iron tower or roof.
Electric Specification
Model NO TQJ-824/896-10D
Frequency Range-MHz 824~896
Bandwidth(MHz) 70
Gain-dBi 10
HorizontalBear width° 360
VerticalBear width° 18
VSWR ≤1.5
InputImpedance -Ω 50
Polarization Vertical
MaximumPower -W 100
Connector N-female
Mechanical Specifications
Roddiameter (MM) Φ35-1200
Weight-kg 0.4
