High Frequency Online N-C6-20K Series

SKU: FS00018891

Reproduction is welcome and allowed for free circulation only.

Key features
��High frequency and double conversion online UPS
�� Single phase, Power Factor 0.8�� Fully digitized microprocessor control�� Wide input voltage range�� Advanced PFC technology�� Self-testing when UPS startup�� Advanced battery management�� Automatic battery charging in UPS off mode�� Lightning and surge protection�� Short circuit and overload protection�� Smart RS232 communication with monitoring software�� Battery voltage and load capacity display�� SNMP card optional�� LCD display and EPO��ECO Function optional�� N+X parallel design optional

Technical Specifications
ITEM
MODEL
N-C6K
N-C6KS
N-C10K
N-C10KS
N-C15KS
N-C20KS
Capacity
VA / Watts
6KVA / 4.8KW
10KVA / 8KW
15KVA / 12KW
20KVA / 14KW
Input
Normal voltage
220VAC, L+N+G
Input Voltage range
120V-275V
Frequency range
50/60��10%
Input power factor
>0.99(220VAC,full R load)
Generator
Support generator input(Generator rating��2*UPS rating
Output
Voltage range
220VAC+-1%
Frequency range
48Hz/54Hz(AC mode), 50HzX(1��0.1��)(Battery mode)
Wave form
Pure Sine Wave
Transfer Time
0 ms
Distortion (Full Load) linear load
< 3%
distortion (Ful l Load) nonlinear load
< 5%
Overload capacity
105%~125% ,1min then transfer to bypass and alarm. 125%~150% 30s then transfer to bypass and alarm,1min then cut off output. >150% ,0.5s then transfer to bypass and alarm.
Load peak ratio
3:1(max)
Battery
Type
Maintenance free valve regulated lead acid (VRLA) battery
Battery voltage
192VDC
192VDC
192VDC
192VDC
192VDC
192VDC
Battery Capacity
internal 16*7AH
External
internal 16*7AH
External
External
External
Around backup time (Full load)
4Mins
up to external battery capacity
3Mins
up to external battery capacity
Around backup time (Half load)
12Mins
9mMins
up to external battery capacity
Recharge time
7 hours to 90%capacity
up to external battery capacity
7 hours to 90%capacity
up to external battery capacity
LED Display
LED
Load level / Battery level / Battery mode / Line mode / Inverter /B ypass /Over load / Fault
Audible Alarm
Battery Mode
Beeping every 4 seconds (re-settable) and every second when battery
Overload
Beeping twice every second
UPS Fault
Beeping Continuously
Bettery low/charger fault
Beeping every 1 second
Bypass mode
Beeping every 2 min
L/N inverse
Beeping every 2 min
Communications
RS-232 Interface
With monitoring software
Working Environment
Working temperature
- 20��~40��
Humidity
0-95% non-condensing
product dimension
WxDxH (mm)
248*500*616
240*500*460
248*500*616
240*500*460
248*500*616
248*500*616
Package size
WxDxH (mm)
700*385*851
595*390*578
700*385*851
595*390*578
700*385*851
700*385*851
Package weight
N.weight(Kg)
57
18
67.5
20
35
35
Gross weight(Kg)
71
23
77.5
27.5
45
45
optional functions
ECO
optional
EPO
optional
LCD display (optional)
input / output VAC & HZ, Load Rate,Battery Rate,Temp.
REMARK
C*k --- Standard Type, C*Ks(-N)---- Long Time Type
