| ●Low voltage alarm and shutdown. | ||||
| ●Over voltage shutdown. | ||||
| ●Over load protect. | ||||
| ●Short-circuit protect. | ||||
| ●Over heat protect. | ||||
| ●Reverse polarity protect. | ||||
| ●Advanced heatsink design and optimum component layout. | ||||
| ●Standard AC outlet. | ||||
| ●LED red/green indicator. | ||||
| ●Super Surge capacity to start difficult loads. | ||||
| Overview |
| Specification | Model1 | Model 2 | Model 3 | Model 4 | Model 5 | Model 6 | Model 7 | Model 8 | Model 9 | Model 10 | Model 11 |
| Max long term power output | 75watt | 120watt | 150watt | 200watt | 300watt | 400watt | 500 watt | 600 watt | 800watt | 1000watt | 1200watt |
| Spike output power(peak) | 120watt | 250watt | 300watt | 400watt | 500watt | 600watt | 800 watt | 1000 watt | 1300watt | 1600watt | 1900watt |
| Input voltage range | DC 10V-14.5V | ||||||||||
| Output voltage range | AC 110-120V / 220-240V | ||||||||||
| Output frequency | 60±3Hz / 50±3Hz | ||||||||||
| Output waveform | modified sine wave | ||||||||||
| Optimum efficiency | more than 90.5% | ||||||||||
| No load current draw | <=0.4A | <=0.25A | <=0.25A | <=0.3A | <=0.3A | <=0.35A | <=0.4A | <=0.45A | <=0.5A | <=0.5A | <=0.6A |
| Cooling Fan | yes | ||||||||||
| Input over voltage shutdown | 14.5-15.8V | ||||||||||
| Input under voltage shutdown | 9.5-10V | ||||||||||
| Overload shutdown | more than 600watts | ||||||||||
| Operating temperature range | 0-55 degrees centigrade | ||||||||||
| Storage temperature range | 0-60 degrees centigrade | ||||||||||
| Test mark | CE | ||||||||||
| QTY/carton (pcs) | 50 | 50 | 40 | 40 | 20 | 20 | 16 | 16 | 10 | 10 | 10 |
| Package L×W×H( cm) | 47.5*29*57 | 57.5*34*43.5 | 56.5*31*36 | ||||||||
| Weight(Kg) | 15 | 17.5 | 21 | 23.5 | 22.5 | 23 | 21 | 22 | 22 | ||
