| ●Micro Processsor Control | |||||
| ●MP3, MP4 Charging function | |||||
| ●Automatic Voltage Regulation | |||||
| ●Over voltage Protection | |||||
| ●Over Temp. Protection | |||||
| ●Short Circuit & Over load protection | |||||
| ●Low battery protection | |||||
| ●High Efficient DC-to-AC conversion.minimizing energy loss | |||||
| ●Application for Fan, light ,TV and office Appliances | |||||
| Overview |
| Product | Requirements | Model 1 | Model 2 | Model3 | Model 4 |
| Power (VA) | SK-B200VA | SK-B350VA | SK-B650VA | SK-B1000VA | |
| Input | Voltage | DC10-15V | DC 20-30V | ||
| Frequency | 50Hz/60Hz | ||||
| Output | Voltage | AC220V+-10% | |||
| Capacity | 140W | 245W | 455W | 700W | |
| Frequency (Inverter Mode) | 50±3HZ | ||||
| Power factor | 0.7 | ||||
| Output Wave | Modified Sine Wave | ||||
| Protection | Low battery | yes | |||
| Over Volt. | yes | ||||
| Over Temp. | Higher than 100 C | ||||
| Over load | the SK200/350 Green LED light,and the SK650-1500 beeping | ||||
| Over Short | Output model: the inverter output turn off /Input Model:the Fuse Protection | ||||
| Packing way | Qty/carton | 8 | 8 | 4 | 4 |
| Carton ShippingWt. | 20 | 24 | 20 | 20 | |
| Carton Dimensions (mm) | 415×330×220 | 415×330×220 | 355×275×475 | 355×275×475 | |
| Acoustic | Noise level | ≤50dB | |||
| Environmental | Temperature | -5-60 DegreeC | |||
| Humidity | 20% to 90% | ||||
