| Capacity | 425VA(250W)625VA(375W) | All-weather surge
max load | 1440W |
| turn to battery output under voltage | 95/175VAC | Outputterminal (6 terminals) | 12A/6Amps |
| Turn to battery output over voltage | 145/265VAC | Output waveform | Square wave |
| lnput frequency | 57-63Hz/47-53Hz | Operatingtemperature | +32F-95F(0-35 ) |
| lnverting output voltage | 120/220VAC±10% | Operating relativehumidity
| 0~95% no condensation |
| lnverting output frequency | 60/50±0.5Hz | Recharge timeof battery | 8h after discharging completely |
| Transititon time | <10ms | Battery life | 3-6years (Depending on discharge
times and ambient temperature) |
| UPS outputs max load(3Terminals) | 425VA(250W)625VA(375W) | Running timeof battery | 4~20min (Depending on load) |
| NW(kg) | 4(425VA)4.5 | Outline size (mm) | 310× 70× 75(The outline size of
NW(kg) 4(425VA) 4.5(625VA) 425VA and 625VA is the same. ) |
Function(UPS-B uninterrupted power supply)
