Application:

High quality and availablity of energy adapted to suit specific critical needs,covering a vast range of applications.Applyed to home pc,move theatre,small office,sensitive electronic equipment,small precision electronic instrument.

Manual Main Features:

Replaceable Battery Design.
intelligent Battery Management.
Short Circuit and Overload Protection.
Surge protected outlets available for convenience.
Microprocessor Controlled guarantees high reliability.
Advanced PWM technology for inverter output.
with LED display
AVR function,inner installed examination circuit for too low or too high voltage,can connect with the power generator.
Auto Restart while AC Recovery for Best power 500VA/600VA/650VA
This model will automatically switch to battery mode and power the load via battery until battery low .

Specifications:

MODEL		EA1150- 500	EA1150-600	EA1150-650
CAPACITY		500 VA/ 300 W	600 VA/ 360 W	650 VA/ 390 W
INPUT
Voltage	Nominal Voltage	110/120 VAC or 220/230/240 VAC
	Acceptable Voltage Range	90-145 VAC/150-290 VAC
Frequency Range		50 Hz
OUTPUT
AC Voltage Regulation (Batt. Mode)		±10%
Frequency Range (Batt. Mode)		50 Hz or 60 Hz
Transfer Time (Typical)		2-6 ms
Waveform (Batt. Mode)		Modified Sinewave / Sine wave
BATTERY
Battery Type & Numbers		12 V 7 Ah x 1	12 V 7 Ah x 1	12 V 9 Ah x 1
Back up Time(at a PC load		8minuters	8minuters	15minuters
Typical Recharge Time		10 hours to 90% after complete discharge
INDICATORS
AC Mode		Green LED lighting
Battery Mode		Green LED flashing every 4 seconds
Low Battery at Battery Mode		Green LED flashing every second
Fault		Red LED lighting
Battery Fault at AC modes		Green LED flashing three times every 2 seconds
Battery Week at AC modes		Red LED flashing every 2 seconds for 30 seconds
Overload		Red LED flashing every twice every second
ALARM
Battery Mode		Sounding every 4 seconds
Low Battery		Sounding every second
Fault		Continuously sounding
PHYSICAL
Dimension, D X W X H (mm)		280x260x95		280x260x95
Net Weight (kgs)		5.5	6.2	6.8
ENVIRONMENT
Humidity		0 to 90% Relative Humidity(Non-condensing)
Operating Temperature		0°Cto 40 °C
