SVC 0.5-30KVA Servo AVR

Артикул: FS00019527

Reproduction is welcome and allowed for free circulation only.

Main Features ●Automatic voltage regulation
●Protection against Low voltage & over voltage
●Wide input voltage range
●Short circuit & over load protection
●Selectable delay Time

Overview

Specification		SVC-500VA	SVC-1000VA	SVC-1500VA	SVC-2000VA	SVC-3000VA	SVC-5000VA
Input	Phase	Single phase
	Voltage	AC150V-250V/50V-130V
	Frequency	50Hz/60Hz
Output	Voltage	220V±3%,110V±6%
	Capacity	400W	800W	1200W	1600W	2400W	4000W
	Frequency	50Hz/60Hz
Protection	Low Volt.	AC184V±4V
	Over Volt.	AC246±4V
	Delay	3-7sec/3-7min(Optional)
	Over load/short Circuit	Yes
Packaging	pcs per Cartion	4			2		1
	Shipping Wt.(KG)	18	25.8	29.6	24.5	26.8	20
	Package Dimensions(mm)	430240360	550505210		590335235	600360270	540305256
Efficiency	AC-AC	>95%
Acoustic	Noise level	≤50dB
Environmental	Temperature	-5℃~45℃
	Humidity	20% to 90%
QTY(pc)	20FT	3000	1840	1840	1200	960	660

Specification		SVC-7500VA	SVC-10KVA	SVC-10KVA	SVC-15KVA	SVC-20KVA	SVC-30KVA
Input	Phase	Single phase 176-260
	Voltage	AC160V-250V
	Frequency	50Hz/60Hz
Output	Voltage	220V±3%
	Capacity	6000W	8KW	8KW	12KW	16KW	24KW
	Frequency	50Hz/60Hz
	Power factor	0.8
Protection	Over Voltage protection	AC246V±4V
	Low voltage protection	AC184±4V
	Over load/short Circuit	Yes
Packaging	pcs per Cartion	1
	Shipping Wt.(KG)	30.5	34	46.5	61.2	63	96
	Package Dimensions(mm)	505365300		425410675	480400850	480400850	960530460
Efficiency	AC-AC	>95%
Acoustic	Noise level	≤50dB
Environmental	Temperature	-5℃~45℃
	Humidity	20% to 90%
QTY(pc)	20FT	465	465	235	170	170	115
