| Overview |
| Specification | SVR-500VA | SVR-1000VA | SVR-1500VA | SVR-2000VA | SVR-3000VA | SVR-5000VA | |
| Input | Phase | Single phase | |||||
| Voltage | AC150V-250V/50V-130V | ||||||
| Frequency | 50Hz/60Hz | ||||||
| Output | Voltage | 220V±3%,110V±6% | |||||
| Capacity | 400W | 800W | 1200W | 1600W | 2400W | 4000W | |
| Frequency | 50Hz/60Hz | ||||||
| Low Volt. | Optional | 184V±4V | |||||
| Over Volt. | Optional | 246V±4V | |||||
| Protection | Auto Return | Optional | |||||
| Over heat | Optional | ||||||
| By pass | No | ||||||
| Delay | 3-7sec/3-7min(Optional) | ||||||
| Over load/short Circuit | Yes | ||||||
| Packaging | pcs per Cartion | 4 | 1 | ||||
| Shipping Wt.(KG) | 16.5 | 21.5 | 29.5 | 33.5 | 15.3 | 22.2 | |
| Package Dimensions(mm) | 380*320*395 | 435*370*475 | 400*260*310 | ||||
| Efficiency | AC-AC | >95% | |||||
| Acoustic | Noise level | ≤50dB | |||||
| Environmental | Temperature | -5℃~45℃ | |||||
| Humidity | 20% to 90% | ||||||
| QTY(pc) | 20FT | 2300 | 1450 | 1450 | 1450 | 860 | 860 |
