Picture of JBK3(DK3)machine tool control transformer

JBK3(DK3)machine tool control transformer

SKU: FS00019595
Reproduction is welcome and allowed for free circulation only.

Application(JBK3(DK3)machine tool control transformer)
JBK3 series machine tool control transformer is a kind of new product by reference to sample of SIMENS Company, it accords with standards like VDE0550, IEC204-1, IEC439, GB5226, etc. It is suitable for AC circuit of 50 ~ 60Hz, output rated voltage ess than 220V , input rated voltage less than 500V, worked as control power supply for mechanical equipment and general electrical appliance and as power supply for work lighting and signal lamp.
Model and its meaning(JBK3(DK3)machine tool control transformer)
Overall size(JBK3(DK3)machine tool control transformer)
Installation size(JBK3(DK3)machine tool control transformer)
Model Overall size(mm)Hole distance for installation(mm)Installation hole
K or K×J(mm)
Fmax
(mm)
BmaxDmaxEmaxAC
JBK3-40、6378728956±0.451±24.8×912
JBK3-10085859464±0.466±24.8×912
JBK3-160969110984±0.473±25.8×1114
JBK3-2509610510984±0.487±25.8×1114
JBK3-40012010912390±0.490±27×1218
JBK3-630150112150122±0.590±27×1222
JBK3-1000160195151126±2152±27×1218
JBK3-1600184220163140±2176±27×1218
JBK3-2500200250171172±2200±27×1218
