Picture of X-8A Fiberi Optic Sectopmeter

X-8A Fiberi Optic Sectopmeter

SKU: FS995776
X-8A Fiberi Optic Sectopmeter
Reproduction is welcome and allowed for free circulation only.

X-8A have fast test function for photometry and colorimetric parameters, automatic generation of database to prepare for post-processing, all parameters can be set upper and lower limits, output signal to mechanical device, particularly suitable for the production line of the LED light source for quick sorting.


Trigger mode: level trigger and switch trigger.

Output signal: level

Test parameter: start-up time, relative spectral power distribution, chromaticity coordinate, correlative color temperature, rendering index, color difference, peak wavelength, luminous flux, etc.

 Wavelength range : 380nm~780nm

Wavelength accuracy : ±0.3nm

Repeatability of chromaticity coordinate : ±0.001(Under  standard illuminator A)

Sampling interval : 1nm/5nm

Photometry repeatability : 1%

CCT range : 1000K~100000K

 Dominant wavelength range : 380nm~700nm

 Sensor : 2048 unit array CCD

Integration time : 6μs~10s

Fiber connector : SMA 905
 Computer interface : USB 2.0
 Interface database in Excel format
Operating system : Windows2000/XP/Vista
