| ● Automatic voltage ragulation(AVR) | ||||
| ● Wide Input Voltage Range Option | ||||
| ●High/Low Voltage Protection | ||||
| ●Overload/Short Protection | ||||
| ●Cool start computer even there is no main power | ||||
| ●Automatic recharge even UPS is off | ||||
| ●Beeping Alarm | ||||
| ●Colored LED display | ||||
| ●Frequency Selection Automatically | ||||
| ●Intelligent Battery Management | ||||
| ●Smart RS232and RJ11 Option | ||||
| ●Compatibility with generators | ||||
| ●Compatibility with generators | ||||
| Overview |
| Product | Requirements | Model 1 | Model 2 | Model 3 | Model 4 | Model 5 | Model 6 | Model 7 |
| Power (VA) | PCM-350 | PCM-500 | PCM-650 | PCM-800 | PCM-1000 | PCM-1200 | PCM-1500 | |
| Input | Voltage | 120 VAC or 220/230/240VAC ±25%(145-280V±5V Option) | ||||||
| Frequency | 60/50Hz +/-10% | |||||||
| Output | Voltage (Inverter Mode) | 120 VAC or 220/230/240VAC ±10% | ||||||
| Capacity | 350VA/210W | 500VA/300W | 650VA/360W | 800VA/480W | 1000VA/600W | 1200VA/720W | 1500VA/880W | |
| Frequency (Inverter Mode) | 60/50Hz +/-10% | |||||||
| Transfer Time | 6MS typical | |||||||
| Waveform | modified-Sinewave | |||||||
| Protection | Spike & Surge Suppression | yes | ||||||
| Over/Under Volt. | Switch to Bat.O / Pwhen Mains over regulation range | |||||||
| Over load /short Circuit | Fuse & current limited for both Mains and Battery modes | |||||||
| Function | Cool start | Cool start computer even there is no main power | ||||||
| Automatic recharge | Automatic recharge even UPS is off | |||||||
| Battery | Type | Lead-Acid maintenance-free | ||||||
| Dc Bus | 12V4.5Ah | 12V7.0Ah | 12V9.0Ah | 12V7.0Ah | 12V7.0Ah | 12V9.0Ah | ||
| Number | 1PC | 1 PC | 2 PCS | |||||
| Recharge time | 8hours≥90% | |||||||
| Back up time(one PC) | 5-8mins | 8-15mins | 10-18mins | 15-25mins | 20-30mins | 20-30mins | 25-45mins | |
| Physical | Weight (KGs) | 4.5 | 5 | 5.5 | 6.5 | 10.5 | 11 | 11.5 |
| ShippingWt. | 5 | 5.6 | 6 | 7 | 11 | 11.5 | 12 | |
| Product Dimensions (mm) | 335*95*160 | 355*120*195 | ||||||
| Package Dimensions (mm) | 395*360*230 mm/ 2 PCS in 1 Carton | 435*395*275/ 2 PCS in 1 Carton | ||||||
| Soft ware | Windows & NT | Auto save & shut down | ||||||
| Efficiency | AC-AC | 1 | ||||||
| DC-AC | 0.6 | |||||||
| Acoustic | Noise level | ≤45dB | ||||||
| Environmental | Temperature | -5-45 DegreeC | ||||||
| Humidity | 20% to 90% | |||||||
| Power Outlets | No. and types | 2SOCKETS | 3SOCKETS | |||||
