180w Transparent solar panel

Catelogue: BIPV Solar Panels

Hits:

Efficient

DurableandStrong

Doubleglass

Easyinstallation

Product Details :

BIPV Solar Module ( Building Integrated Photovoltaics )

Introduction:
BIPV is the abbreviation of Building Integrated Photovoltaic system. It is a new concept of
Converting solar energy into electricity by integrating solar cell into building envelope.
This industry is full of energy and creativeness which stimulates the interest of application
Developers and architects, and the meantime, creating a new era for architectural design while
Protecting our earth.

Features:
--can replace conventional glazing on Atria, Facade, Wall, Awnings, Pergola, Roof, Skylights,
Parapet Cladding
--adds tremendous aesthetic value
--provides attractive combinations when used with conventional building material
--sustainable building material.
--sturdy, leak-proof and all-weather proof, with the ability to withstand high wind, hail,
Humidity and high ambient temperature
--needs no fuel, has no moving parts and needs negligible maintenance
--can be customized

PL ENERGY Strength:
PL ENERGY's BIPV Module & System offers a wide variety of BIPV product series allowing our
Customers to have their own choice in system design. PL ENERGY's Double Glazed BIPV Module is
One new building material which integrates power generation, sound insulation, heat
Insulation, fire resistant and safety; It meets both architecture and aesthetic requirements.
The modules are tested with IEC61215, IEC61730, UL1703, and China Golden-sun Certification.

PL ENERGY's R&D team has self developed the Double-Glazed BIPV Module and make it into
Industrialization. With the successful formation in the crystalline solar cell production
Line, the vertical expansion enables the company to acquire the solar PV chain from solar cell
Production to solar PV module, to BIPV system design.

Spec:
MODULE: Glass + PVB and cell layer + glass
MODULE Size: Min. 300 * 300 mm, Max. 2300 * 3600 mm
POWER OF STANDARD CRYSTALLINE MODULE:
150 W/ ( 5% transmittance)
140 W/ ( 10 % transmittance)
130 W/ ( 20 % transmittance)
120 W/ ( 25 % transmittance)
110 W/ ( 30 % transmittance)
100 W/ ( 35 % transmittance)
90 W/ ( 40 % transmittance)
80 W/ ( 50 % transmittance)
GLASS TYPE: Tempered glass/Heat strength glass / Chemical tempered glass
MODULE TYPE: Flat PV module, Curve PV module, Insulated PV module (U value: 1.2W /m)
TYPICAL MODULE TYPES:
3.2 mm glass+2.28 mm PVB + 3.2 mm glass
6 mm glass+2 28 mm PVB + 6 mm glass
8 mm glass+2.28 mm PVB + 8 mm glass
8 mm glass+2.28 mm PVB + 10 mm glass
10 mm glass+2.28 mm PVB + 10 mm glass
CELL TYPE: Monocrystalline, Polycrystalline, Amorphous
SYSTEM VOLTAGE: Max. 1000 W
TYPICAL VALUE: 26%
EXECUTION STANDARD: IEC 61215, GB/T 95361998
Supporting and fixing method: Point fixing, Hidden frame, Semiexposed frame
CELL COLOR: Blue, Bronze, Grey, Black, Brown, Red, and other colors on request
CELL DEMENSION ( mm ):
Crystalline: 125*125 (Semitransparent), 156*156 (chamferable)
Amorphous: 1400*1100 2500 * 2240 ( Max )
OTHER FUNCTIONS:
Safe protection; Customized panels; Noise insulation; Antiglare protection; Sun shading;
Whether protection; 1400, Max. )
CELL EFFICIENCY:
Monocrystalline: 15 21%
Polycrystalline: 14 17 %
Amorphous: 6 9 %
GLASS TRANSMITTANCE (front pane): > 91%
FRONT GLASS TYPE: Low iron solar glass;
PRODUCT GUARRANTEE: 5 years
PERFORMANCE GUARANTEE:
10 years at 90 % power performance;
25 years at 80% power performance;
