Payment & Shipping Terms:

1.Special design :recode fuction

2.weight:120G

3,work distance : 250 meters

4,Frequency band :2.4GHZ

6Mode :full -duplx


Wireless CB Portable Digital Two Way Radios 2.4GHZ With Recode Fuction

Instruction :

Power ON/OFF:

1.Power On :Long press the Key "ON/OFF"(Switch Machine) till the LED light become red.

2.Power Off :In standby mode a long press ON / OFF key to eliminate the red light off.

Configure Code :

1. Renyiyitai Machine is in on mode ,Long press ON/OFF key to eliminate the red light off, then long press ON/OFF key till red light twinkle, then is on Configure Code status.

2. Make the other machine on Configure Code status as Step 1

3.

A.If Configure Code successful within 6 seconds, red light twinkles three times and machine goes to synchronous mode, synchronization ok then come to call status.

B.If Configure Code failed within 6 seconds, red light twinkles one time and exits from Configure Code status then return to standby mode.

Low Battery : Power light twinkle if is low voltage when machine is in standby mode, please replace battery.

Call Status:

1. Long press the ON/OFF key to make the machine power on and light becme red then go to synchronous mode.

2. Make the other machine go to synchronous mode as step 1.

3.

A:Enter in to call status if boht machine synchronization ok.

B:If synchronization failed have to redo again till synchronization ok then can enter into call status.

4. Any party shut down the machine or power down will end the call.

Accessaries:

Battery: Polymer lithium battery 2000mA/h 3.7V, Charge limit voltage of 5V.

Charger: Input AC voltage 110V ~ 240V, 50/60Hz , Output 5V/1A , pass safety Certification.

Details

1) Wireless frequency 2.4GHz

2) Full-duplex hands-free voice call, voice loud and clear
3) Improved frequency-hopping technology, super error-correcting and anti-jamming capability
4) certification standards RoHS, CE, CCC

5) 83 effective communication channels6) Portable handset

Applicable Scope:

-Widely Use: Film, Security, Sport, Hospitality, Construction

1) Electric power construction job site overhaul
2) Electricity System and equipment maintenance
3) Mining ,Construction sites contact
4) Army patrols communications
5) Railway Construction Contact
6) Oil Field Construction Contact
7) Golf Course intercom
8) Airport personal deployment command
9) Traffic Police on duty communication
10) Police patrol communication
11) Travel, sports, referee use
