Picture of GCA Battery Charger

GCA Battery Charger

SKU: FS00019544
Reproduction is welcome and allowed for free circulation only.

Main Features ●Commutate silicom technology
●Output current adjustable.
●Output voltage&current display.
●Float voltage charging
●Application:Automotive repairing factory, diesel motor
set,motorcycle, safty lighting, etc.
Overview

BATTERY CHAGER SPECIFICATION
Model GCA-6A GCA-10A GCA-15A GCA-30A
Nominal Battery Voltage 12V/24V DC 12V/24V DC 12V/24V DC 12V/24V DC
Maximum Output-Current(Amps ave) 5A DC 10A DC 15A DC 30A DC
Total Battery Capacity (recommanded range) 30Ah~150Ah 100Ah~200Ah 200Ah~300Ah 100Ah~500Ah
Maximum total load on batteries during charging 6A DC 10A DC 15A DC 30A DC
Maximum Voltage Electronic Regulation 14.50V, 25
Mains Supply Voltage 220~240Vac 50~60Hz
Maximum Consumption 72VA 120VA 180VA 360VA
Tolerance to Mains supply distortion 16 THD
Mains protection Reverse polarity, short circuit
Output Protection short circuit, charging full
Temperature range -10~45℃
Metering:Amps Analogue Moving Coil 10A FSD 15A FSD 20A FSD 50A FSD
Cabinet:W×D×H 200×163×125 200×163×125 200×163×125 200×163×125
Connections:input 5A 3pin 2m cable 10A 3pin 2m cable 10A 3pin 2m cable 10A 3pin 2m cable
Connections:output 100A Binding posts 100A Binding posts 100A Binding posts 100A Binding posts
Connections:output cable minimum size 10mm2 Per2m 10mm2 Per2m 10mm2 Per2m 10mm2 Per2m
