Image de 3400~3600mhz sector antena 15dBi

3400~3600mhz sector antena 15dBi

SKU: FS00034436
3400~3600mhz sector antena 15dBi
Reproduction is welcome and allowed for free circulation only.

ELECTRICAL
Model GA-SP-3400-3600-15-65
Frequency Range 3400-3600-MHz
Bandwidth 200-MHz
Gain 15-dBi
Beamwidth 65/17
F/B ratio ≥25-dB
VSWR ≤1.5
Polarization Vertical
Max power 400 -W
Nominal Impedance 50 -Ω
MECHANICAL
Connector­­­ N female or customized
Dimension 500X174X85-mm
Weight 2-KG
Mounting Mast Diameter Φ40 to Φ65-mm
Operating Temperature -40 to +60-
Relative Humidity 5% to 95%
Rated Wind Velocity 60-m/s
