3.5GHz Integrated Antenna with Enclosure
Model GA3500D20WE
Freq. Range 3400-3600 MHz
Bandwidth 200MHz
Gain 20dBi
V.S.W.R <1.5Type; Max 2.0
Horizontal Beamwidth 16º
Vertical Beamwidth 16º
Max Power 50 W
Polarization Vertical or Horizontal
Impedance 50 ohm
Connector SMA Female
Antenna Dimension 305 x305 x 70 mm
Inside Dimension 186x186x40mm
Weight 2.5kg
Radome Material Anti-UV ABS
Enclosure Material Aluminum Die Cast
Color White
Mounting mast diameter Ø30 to 50mm
