Product Description::SPECIFICATION
Size:25.3x25.3x7mm/25.3x25.3x9mm
Dieletric Antenna
Center Frequency 1575.42 MHz±3 MHz
V.S.W.R 1.5 : 1
Band Width ±5 MHz
Impendence 50 ohm
Polarization Type RHCP
LNA/Filter
LNA Gain(Without cable)10~30 dB Typical
Noise Figure 1.5 dB
DC Voltage 2.2~5 V
DC Current 5~15 mAMechanical
Cable RF1.13 or others
ConnectorIPEX / MMCX or othersEnvironmental
Working Temp -40~+85
Humidity 55%~75%RH
Waterproof IP67
Limited warranty 12 months for parts and 12 months for labor.
Support URL: http://www.firstsing.com
Support Phone Number: 86-0755-29889139
