Keystone Jack の画像

Keystone Jack

SKU: FS00040368
Keystone Jack
Reproduction is welcome and allowed for free circulation only.


MG-1158 Cat.6 RJ45 Keystone Jack
other Name : Cat6 In-line Coupler /keystone jacks/RJ45 couplers/network connectors
RJ45 Cat 6 in-line Coupler,UTP, FTP for network cabling
Cat 6 in-line Coupler,
UTP for network cabling,structured cabling and telecom.
1. RJ45 jack contact,phosphor bronze,nickel-plate with 50 micro-inch gold-plating.
2. Housing:ABS +PC,UL94V-0
3. Insertion force:900g for eight contacts.
4. Retention strength:7.7kg between jack and plug
5. Operation temperature:-40 to 80 degree celsuis
6. Durability:jack 750 cycles plug-jack mating and unmating test,insertion cycles at 20 cycles/minute maximum.
7. Contact resistance test per 100 cycles.
8. IDC:maximum 200 punching times.
9. Category 6 performance is in compliance with the ANSI/TIA/EIA 568 B.2-1 standard.
10.VSPD:UTP connectors.
