Picture of Keystone Jack

Keystone Jack

SKU: FS00040372
Keystone Jack
Reproduction is welcome and allowed for free circulation only.

1. MG-1121 Cat.3 RJ11 Keystone Jack
1.Meet TIA/EIA-568-A and TIA/EIA-568-B Category 5E requirements.
2.Meet TIA/EIA TSB-40
3.Meet ISO/IEC Generic Cabling Standard 11801
4.Meet CENELEC Generic Cabling Standard EN50173
5.Angle: 90 Degree
6.Termination: 110 IDC type

2. Electrical:
1.According to UL 1863
2.Current rating: 1.5 Amp Max.
3.Voltage rating: 150 Volts
4.Contact resistance: 20 m-ohm
5.Insulation Resistance: 500M-ohm
6.Dielectric Withstand Voltage: 1000 V AC RMS, 60Hz 1min

3.Materials:
1.Housing: PC UL94V-0
2.IDC: PC UL94V-0, Accept 22-26 AWG Solid Wire.
3.PCB: FR4 1.6mm(0.04") thickness, 2 layers
4.Contact: PC Ul94V-0, 0.45mm(0.018") Diameter Phosphor bronze with 3 U" to 50 U" Gold plating on contact area
