Picture of Keystone Jack

Keystone Jack

SKU: FS00040377
Keystone Jack
Reproduction is welcome and allowed for free circulation only.


MG-1138 Cat.5E RJ45 Keystone Jack
UTP Cat.5e/Cat.6 Keystone Jack 180 degree

UTP Cat.5e/Cat.6 Keystone Jack 180 degree
Voltage125 VAC RMS
Current1.5 AMP
Contact resistance100 Milliohms MAX
Insulation resistance1000 Megohms MIN @ 500 VDC
Dielectric strength750 VAC RMS 60Hz, 1MIN
Storage-40~ +85��C
Operation0~ 70��C
Conform toTIA/EIA 568B Category 5e
Mates with modular plugFCC part 68, Subpart F.
Housing materialPC UL94V-0
Jack housing materialPBT+15%GF UL94V-0
PCB materialFR-4 Thickness:1.6mm
Contact materialPhosphor bronze stamp PIN T=0.35mm
IDC Contact materialPhosphor bronze T=0.50mm with nickel plating
WireAWG 24-26
Packaging500 PCS/Carton,Size 40*29*53
GW7.3 kg
