Cherry Trail-CR Intel® Atom x5-Z8300 MINI PC

CPU:Cherry Trail-CR

Processor:Intel® Atom x5-Z8300

Chipset:Integrated into CPU

Display:Intel® HD Graphics
Microsoft® DirectX® 11
1x VGA
1x HDMI

Memory:Onboard 2G DDR3L high speed Memory

Storage:Onboard eMMC 32G
1x mSATAII Port for SSD, 1x TF card Slot

Ethernet:1 x RJ-45 (Gigabit LAN)

Audio:Realtek® High Definition Audio
Digital audio via HDMI connector
1x Audio out&Mic in jack on the front panel

Ethernet:1x Realtek® Gigabit Ethernet Controller
1x RJ45 port on the back panel

Expansion Slots:1x Mini-PCI Express® (3G module expansion)
1x M-SATA (only available for high-end model)

Wireless:Onboard Wifi or Wifi / BT module, Antenna

Dimension:116.6 x 107.2 x 30mm

Expansion Slots:1x Mini-PCI Express® (3G module expansion )
1x M-SATA ( only available for higher configuration )

Peripheral interfaces:
1x USB3.0 + 3x USB2.0
1x HDMI 1x VGA
1x RJ45(1000M) 1x COM
1x JAHC Switch (Default OFF) for extended RTC
1x DC-IN Jack (5V/3A)

OS Support:Windows® 8, 10 & Android 5.1

SystemBIOS:AMI EFI BIOS; ACPI

Cooler:Fanless

Operating Temperature:0℃ to +40℃
