WIFI Digital Wireless Video Doorphone , 3.5" Inch Screen

With the WIFI network being more and more popular and covering more and more areas, the WIFI network has been widely used in smart home products. WIFI smart cat eye door phone will improve the safety of your family. With this door phone,you can monitor you home anytime and any where by WIFI network when you are outside. When you are at home, it will serve you as video door phone, easy to operate and install. Widely used in family unit, single-family housing, villa, office and other places.


Function:

1. The screen will display LOGO when turn on, and the LOGO can be changed as your request
2.3.5’’ inch screen
2.Image frame rate: 20 fps
3.Can recognize TF card intelligently and insert or extract the TF card in operation status, If there is a TF card, it automatically convert to video mode and store the video record on TF card.
5.Connect WIFI network:set the network connection by APK software to monitor the home remotely.
6. infrared detect auto: when someone passes the door, the infrared will be triggered, system will start, then the door phone will send signals to mobile phone
Press key: when someone presses the button on the door phone, the door phone will ring and mobile phones will receive a prompt to see the door.
7.Power supply: powered by lithium battery only, It will be in the shutdown status in order to reduce power consumption .when infrared detect the signal of people,it will turn on and connect the WIFI auto,the CALL time can last 16s. Powered by external power source, the door phone will connect the WIFI network all the way, the CALL time can last 3s.

Description of Keys:

1)Front:
At home key ( option key/monitor key):
1.Press the key one time in standby mode, showing that there are someone at home. The door phone will convert to bell mode,at same time the indicator (someone at home ) will last flashing 4s.
2.When enter the menu,it will be up cursor.
3.Press the key again in bell mode, it will be monitor key.
Out of home key( option key):
1.Press the key one time in standby status, showing that there are nobody at home. The door phone will convert to alarm mode and start infrared detecting function,at same time the indicator (nobody at home ) will keep bright 60s.
2.When enter the menu,it will be down cursor.
Playback key(save key/ back key/ end key/on/off key):
1.Press the key, it will play the video or photo record in standby interface.
2.Press the key for 3s, the door phone will turn on/off .
save key/ back key/ end key: press it to return to previous operation in the function menu, to save information when input some information, to end calling when call.
Menu key(end key/confirm key)
3.Open the setting menu in main menu.
Option key:
1.confirm and save the function which you chose.
2.Press the key to stop ringing.

2)Left:
Three gears switch: to adjust the sensitivity of infrared.
First gear: Only the infrared detects the signal one time, will the infrared send signal to the door phone.
Second gear: Only the infrared detects the signal three times, will the infrared send signal to the door phone.
Third gear: Only the infrared detects the signal five times, will the infrared send signal to the door phone.
.

3)Bottom:
Mode key/ delete key:
Press the key to delete photo or video or the information that was input last time in playback /input mode.


In playback mode

(1) Press playback key in standby mode.
(2) it will select the storage location auto.If there is TF card,it will select TF card.If not,it will select memory card.
(3) The photo and video file will be displayed in the form of thumbnail. The format of file name is "[] year month day hour minute second".For example "[F/J]20130530-112956. jpg /3jgp" stands for 11 clock 29 munites and 56 seconds on May 30, 2013,(f stands for the record of Bell, j stands or the record monitoring) .Press out of key or at home key to select the appropriate files .(If there is new visitor photo or video record, it will show ” you have a new visitor information, see or not?” on standby screen).
Press the menu/select key to open the selected photo, or play the selected video .
(4) Delete file: open the selected picture or video, then press the menu key and then press the menu key to confirm the deletion after displaying the delete dialogue box. Or press the playback /return key to cancel the deletion.Directly press the mode key to delete it directly.
(5) Press the playback /return key to return to the previous menu.
