Catelogue: 48V LiFePO4 Battery Pack
Hits:
CEULapproved
built-inprotectioncircuitboard(BMS),
Products Features:
1. Safety: safest Li-Ion battery, CE UL approved, built-in protection circuit board (BMS),
no fire, no explosion
2. Clean and Green energy, no toxic material contained
3. Long life cycle, > 2000 times deep cycle at 1C rate, 6-8 times of lead acid battery
4. No memory effect, highly efficient charge anytime, no reduction of capacity
5. Operation temperature: -20~70C
6. Small size and light weight: 1/2 size of lead acid battery,
70% size of Ni-MH Ni-Cd battery, 1/2 weight of lead acid battery
7. Good performance at high temperature and high temperature resistance
8. Low self-discharge rate: < 3% monthly
Applications:
1. Large-scale electric vehicles: electric bus, electric car, E-Tour Car
2. Light electric car: e-bike, electric scooter,e-motor, electric golf car, forklift,
cleanness car, electric wheelchairs
3. E-tool: electric drill, electric saw, lawn mower and so on
4. Remote control cars, boat, aircraft, toys
5. Solar and wind power generation energy storage devices
6. Small medical equipment and portable equipment
Model | Standard Voltage( V) | Standard Capacity ( Ah) | Size | Weight |
PL48-10 | 48 | 10 | 365.1*138.1*90 (mm) | About 6.0 (kg) |
PL48-15 | 48 | 15 | 280*185*190(mm) | 9(kg) |
PL48-20 | 48 | 20 | 300*300*88(mm) | About 10 (kg) |
PL48-25 | 48 | 25 | 323*171*215(mm) | About 15 (kg) |
PL48-30 | 48 | 30 | 400*165*150(mm) | About 16.5 (kg) |
PL48-40 | 48 | 40 | 530*165*150(mm) | About 22 (kg) |
PL48-50 | 48 | 50 | 360*220*262(mm) | 35.0(kg) |
PL48-100 | 48 | 100 | 430*320*262(mm) | 62(kg) |
PL48-200 | 48 | 200 | 560*360*200(mm) | 68.0(kg) |
