H.264 4CH Economic DVR FJ-7307B
1,4 ch port professional DVR
2,CMS software /3G/ mobile monitoring
3,smart rearch
4, digital zoom
Features:
Support local storage at H.264 compressionUp to support 4ch CIF real-time recording and CIF playback in syncSupply BUILT-IN DDNS domain name, net-work access easier from.Support mobile phone viewer:(Windows Mobile/ Symbian/iPhone/Android/BlackBerry)Support IE browser, sub control software centralized monitoring & managing many DVRs in network(max 255 pcs of DVRs at a time)Support 8 users network view simultaneouslySupport Dual-streamSupport SMTP,UPNP, DDNS, PPPOE, etc, protocolsSupport to send alarm information & screenshot via Email once triggering the alarm6 work operation: preview, recording, playback, backup, network monitoring and mobile monitoring can be operated independently at the same time.Chinese, English, Thai, Russian, French, Spanish, etc.Specifications:
Video | Input | BNC×4,(1.0Vp-p,75Ω) |
CVBS Output | BNC×2,(1.0Vp-p,75Ω),PAL 704*576,NTSC 704*480 | |
VGA Output | VGA×1, Resolution 1024*768 | |
Audio | Input | RCA×1 |
Output | RCA×1 | |
Recorder | Video/Audio Compression | H.264 Main Profile/ADPCM |
Frame Rate | CIF (PAL:25fps,NTSC:30fps) | |
Pre recorder | Max 30 Seconds | |
Image Quality | 6 levels | |
Motion | Trigger Events | Recorder,PTZ,Alarm,E-mail |
Motion Detection | Configurable detection areas 352(22*16) and Sensitivity 5 levels | |
Video Loss | Support | |
Alarm | Input | no |
Output | no | |
Playback | Synchronous Playback | 4-ch |
Search Mode | Date, Time, Event, Channel | |
Back | Back Mode | USB HDD, Network |
Hard Disk | Interface Type | 1 SATA interface |
Capacity | Each interface supports up to 2TB capacity | |
External Interface | Network Interface | 1 RJ-45, 10/100Mbps self-adaptive Ethernet interface |
USB Interface | 2,USB2.0 | |
RS485 Interface | 1 RS-485 interface (for PTZ control) | |
General | Power Supply | 12V/3A |
Power Consumption (without hard disk) | ≤12W | |
Working Temperature | -10°C~+55°C | |
Working Humidity | 10%~90% | |
Dimension | 250(L)×235(W)×45(H) mm | |
Weight(without hard disk) | 2.0KG |
