Overview |
Model No. | SKN-P2000-112A1 | SKN-P2000-124A1 | SKN-P2000-148A1 | SKN-P2000-112B2 | SKN-P2000-124B2 | SKN-P2000-148B2 | |||
Output | AC voltage | 110V±10% | 220V±10% | ||||||
Rated power | 2000W | 2000W | |||||||
Peak power | 4000W | 4000W | |||||||
Waveform (THD) | Pure sine wave (<3%) | Pure sine wave (<3%) | |||||||
Frequency | 60Hz ±0.3% | 50Hz ±0.3% | |||||||
Input | NO load current draw | <1.8A | <1.8A | <1.8A | <1.8A | <1.8A | <1.8A | ||
DC voltage | 12V | 24V | 48V | 12V | 24V | 48V | |||
Voltage range | 10.8~15VDC | 21~30VDC | 41~56VDC | 10.8~15VDC | 21~30VDC | 41~56VDC | |||
Efficiency | > 90% | > 90% | |||||||
DC connector | Cables With Clips or Car Adaptor | Cables With Clips or Car Adaptor | |||||||
Protection | Low voltage alarm | 10.2~10.8V | 20.4V | 40.8V | 10.2~10.8V | 20.4V | 40.8V | ||
Low voltage shut down | DC 9.5V | DC 19.5V | DC 38.5V | DC 9.5V | DC 19.5V | DC 38.5V | |||
Over load | Shut Off Output | Shut Off Output | |||||||
Over voltage shut down | DC 15.5V | DC 30.5V | DC 61.2V | DC 15.5V | DC 30.5V | DC 61.2V | |||
Over thermal | Shut Off Output Automatically | Shut Off Output Automatically | |||||||
Fuses | Short Circuit | Short Circuit | |||||||
Environment | Working temperature | -10°c ~ +50°c | -10°c ~ +50°c | ||||||
Working humidity | 10%~90%RH | 10%~90%RH | |||||||
Storage temperature | -20°c ~ +50°c | -20°c ~ +50°c | |||||||
Package | Machine Size(mm) | 435*199*73 | 435*199*73 | ||||||
Packing Size(mm) | 368*180*120 | 368*180*120 | |||||||
Net Weight | 5.6kg/unit | 5.6kg/unit | |||||||
Gross Weight | 6.5kg/unit | 6.5kg/unit | |||||||
Packing Mode | Carton | Carton | |||||||
Other | Start | Soft Start | Soft Start | ||||||
Cooling Ways | Cooling Fan | Cooling Fan |
