SVB 0.5-30KVA Servo LCD AVR

SKU: FS00019533

Reproduction is welcome and allowed for free circulation only.

Main Features ●Automatic voltage regulation ●Protection against Low voltage & over voltage ●Wide input voltage range ●Short circuit & over load protection ●With delay function ●Built-in servo motor ●LCD display (input volt. input current, outputvolt. Load condition, over load, over V, under V, etc)

Overview

Specification

SVB-500VA

SVB-1000VA

SVB-1500VA

SVB-2000VA

SVB-3000VA

SVB-5000VA

SVB-7500VA

SVB-10KVA

SVB-15KVA

SVB-20KVA

SVB-30KVA

Input

Phase

Single phase

Voltage

AC150V-250V

AC160V-250V

AC-176V-264V

Frequency

50Hz/60Hz

Output

Voltage

AC220V±1%,3%,5% Selectable

Capacity

400W

800W

1200W

1600W

2400W

4000W

6000W

8000W

12KW

16KW

24KW

Frequency

50Hz/60Hz

Protection

Delay

3-7sec/3-7min selectable

Over Volt.

AC246V±4V

Low Volt.

AC184V±4V

Over heat

(Optional)

Cooling system

Natural cooling(Optional)

By pass

Optional

Over load/short Circuit

Yes

Packaging

pcs per Carton

Shipping Wt.(KG)

29.2

31.5

15.3

22.2

57.5

59.2

Package Dimensions(mm)

407*370*425

385*305*350

415*305
*385

520*360
*505

405*430
*670

485*390*850

530*460
*960

Efficiency

AC-AC

>95%

Acoustic

Noise level

≤50dB

Environmental

Temperature

-5℃~45℃

Humidity

20% to 90%

QTY(pc)

20FT

1750

660

570

280

220

165

115
