specifications

SK2202CA

SK2152CA

SK2102CA

SK2062CA

SK2042MA

SK2152MA

SK2102MA

SK2062MA

Bandwidth

200MHz

150MHz

100MHz

60MHz

40MHz

Realtime Sample Rate

1GS/S

Equivalent Sample Rate

50Gs/s

Input Impedance

1MΩ //13pF 50Ω

Rise Time

1.8ns

2.3ns

3.5ns

5.8ns

8.8ns

Timebase Range

1ns/div~50s/div

2ns/div~50s/div

5ns/div~50s/div

X-Y Operation

Bandwidth

200MHz

150MHz

100MHz

60MHz

40MHz

Phase Difference

+ 3 degrees

Display

Color LCD (C) / Mono LCD(M)320×240

specifications

SK2152C

SK2102C

SK2062C

SK2042M

SK2022M

SK2152M

SK2102M

SK2062M

Bandwidth

150MHz

100MHz

60MHz

40MHz

25MHz

Realtime Sample Rate

250GS/S

Equivalent Sample Rate

50Gs/s

Input Impedance

1MΩ //13pF 50Ω

Rise Time

2.3ns

3.5ns

5.8ns

8.8ns

14ns

Timebase Range

2ns/div~50s/div

5ns/div~50s/div

20ns/div~50s/div

X-Y Operation

Bandwidth

150MHz

100MHz

60MHz

40MHz

25MHz

Phase Difference

+ 3 degrees

Display

Color LCD (C)/Mono LCD(M)320×240

Common Specifications

Number of Channel

s2CH;Ext.Trig

Memory

4K per channel

Vertical Sensitivity

2mv/div~5v/div

Vertical Resolution

8bits

Input Coupling

DC, AC ,GND

Trigger Mode

Auto, Normal, Single

Trigger Type

Edge, TV, Pulse

Trigger Coupling

DC, AC, LF Rej, HF Rej

Horizontal Accuracy

+0.01%

Math

＋.－.×.÷.FFT

FFT

Window

Hanning,Hamming,Blackman,Rectangular

Sample

1024 Points

Auto Measurement

Vpp,Vmax,Vmin,Vtop,Vbase,Vamp,Vrms,Vavg,Vover,Vpre,

Freq,Period,Rise,Fall, +Width,－Width, +Duty,－Duty.DelayA,DelayB

Cursor Measure

Manual,Trace,Auto Measure

Storage

10Wave forms,10setups

I/O

USB device

Power

100V­—240V/50VA Max

Net Weight

5KG

Size

300（D）×312（W）×145（H）

Accessories

Probe×2(1×,10×) Power Cord,User manual
