Catelogue: Mono Solar Panels
Hits:
Applies to commercial, residential and utility scale applications
Easily installed ground, roof, building face or tracking system
Smart choice for on-grid and off-grid applications
Reduces electricity bill and creates energy independence
Reliable and virtually maintenance-free power generation
PL ENERGY PLM-185 Series are perfect for largescale ,installations, particularly ground-mounted and commercial rooftop systems. Using reliable and arefully selected components that are tested at the PL ENERGY Center of Excellence, this panel comes with a 25-year performance guarantee of 80% power production.
Product benefits
--Applies to commercial, residential and utility scale applications
--Easily installed ground, roof, building face or tracking system
--Smart choice for on-grid and off-grid applications
--Reduces electricity bill and creates energy independence
--Reliable and virtually maintenance-free power generation
-- Provides clean, quiet and reliable electricity generation
Product features
--High powered modules from 165W to 290W, providing solutions for variety of applications.
--Modules are IEC61730 safety rated for high wind pressure, hail impact, snow load and fire.
--Integrated bypass diodes to protect the solar cell circuit from hot spots during partial shadowing.
--Anodized aluminum frame improves load resistance capabilities for heavy wind loads.
--Our module technology ensures there are no problems of water freezing and warping.
--Low power tolerance of +/-3% helps higher output power, by reducing module string mismatch losses.
--High efficiency 156x156mm photovoltaic cell’s technology for improved performance and reliability, it’s efficiency reach to 17.25%.
--Highly transparent, low-iron, and tempered glass and antireflective coating increases energy yield.
--New eco-friendly packaging minimizes cardboard waste and requires less transportation and storage space.
solar power panel 200W
Maximum power( Pmax) : 200 W
Material: mono-crystalline silicone cells
Open circuit voltage (Voc) : 46.80 V
Short-circuit current ( Isc) : 5.07 A
Maximum voltage ( Vmp): 36.90 V
Maximum current (Imp) : 5.03 A
Size of Module (mm) : 1580*808*40 mm
Weight Per piece (KG) : 15.50 Kg
Module Certificates: TUV,IEC, CE,UL
Pacakge info:
40HQ: 784 PCS. 26 PCS/PALLET, 28 PALLETS/CONTAINER
