| Frequency Range(MHz) | 806-960/1710-2500 | |
| Beam Width | E-Plane | 50° |
| H-Plane | 90° | |
| Gain(dBi) | 8.2dBi/9.5dBi | |
| F/B(dB) | >23 | |
| VSWR | <1.5 | |
| Polarization | Vertical/Horizontal | |
| Max Power(W) | 200 | |
| Impedance(Ω) | 50 | |
| Lightning protection | Direct Ground | |
| Connector | FME male | |
| Max Wind Velocity (Km/h) | 216 | |
| Temperature('C) | -40° to +70° | |
| Dimensions (mm) | 295×210×60 | |
