CAT5E UTP 24AWG 4P TWISTED COPPER CABLE
ITEM					Description
Conductor	material				Bare copper
	Construction				24AWG(1/0.50)
	O.D.				0.5 mm?.02mm
Insulation	Material				HD-PE
	Thickness				0.269MM?.05mm
	O.D.				0.975MM?.03mm
	Elongation				Min.300%
	tensile				Min.1.22kg/m?
Twist PairN/A					color						function
					1. Blue郬hite / Blue						Unused Unused
					2. Orange?/B>White / Orange						Transmit Data +Transmit Data -
					3. Green?/B>White / Green						Receive Data +Receive Data -
					4. Brown White / Brown						Unused Unused
Remark : Network cabling comprises of four pairs of wires, only two pairs are normally used. Despite this, all the pairs should always be wired to maintain the network specification. The cable pair colors, pair numbers and wire descriptions are shown in the table
jacket	Material				PVC
	Thickness				0.615mm?.1mm
	O. D .				5.2mm?.3mm
	Color				According to customer抯 requirement
	Elongation				Min.125%
	tensile				Min.1.41kg/m?
weight	8.7kgs/305m
package	packing				1000FT/305M per box or as customer抯 requirement
	Package				Easy pull out box /wooden drum or as customer抯 requirement
	Boxes size				Ineer box				Outer box(two ineer box in one outer box)
					34.5*34.5*19.5CM				41*35.8*36CM
Application	100 Base-TX, 100 Base-T4, 100VG-AnyLAN, 1000Base-T, ATM
datapass	160m
Cable printing	CATEGORY 5e UTP CABLE 24AWG 4PAIR 1m ............... As customer order
Terms&condition	MOQ			100BOXES
	OEM			Provide Free box/logo design
	Price Term			FOB, CIF, C&F or other (port is shenzhen)
	Payment Term			T/T
	Delivery time			7-15days
	certificate			CE&ROHS
Temperature Rating		75c
ConductorResistance		24AWG: 9.38/100M Max.(at 20)
UnbalanceResistance		5 Percent Max
Capacitance		5600pf/100 meters
		330pf/100 meters
Unbalance
Impedance(ohm)		772KHz: 102?5%(85-117)
		1 MHz-100MHz: 100?5%(85-115)
Attenuation		MHz	0.772			1	8	10		25		63	100
		dB	2.2			2.4	7	7.8		12.5		20.42	26
NEXT		MHz	0.772			1	8	10		25		63	100
		dB	67			65	52	50		44.3		38	35
PSNEXT		MHz	0.772			1	8	10		25		63	100
		dB	63.7			62	49	47		41.3		35	32
ELFEXT:		MHz				1	8	10		25		63	100
		dB				64	46	44		35.8		28	24
PS ELFEXT:		MHz				1	8	10		25		63	100
		dB				61	43	41		32.8		25	21
Return Loss(dB)		MHz				1-20	25	31.25		62.5		100
		dB				23	22.03	21.06		18.05		16.01
Propagation Delay		518ns/100m Max.(10MHZ)
Delay Skew(ns)		45 ns/100m Max.
