Super quality Ambarella A5S88 DSP, WDR, Low stream
- 1/3" 3MP CMOS, Low Illumination
- 3.0 Megapixel@17FPS, 2.0 Megapixel@25FPS
- H. 264, IR Cut Filter
- Support mobile (iPhone, iPad, Android, Symbian, Windows Mobile) and P2P cloud monitoring
- 1 RJ45 10/100M self-adaptive, support ONVIF 2.0/FTP/PPPOE/DHCP/DDNS/NTP/UPnP, etc
- 4mm/6mm/8mm/12mm/16mm HD CS Fixed Lens
- DC 12V
- Optional: Varifocal lens, USB Storage, WiFi, POE, BNC Output, Audio
| Model | |||
| 3MP HD Network IR Dome Camera | |||
| Camera | System Structure | Embedded LINUX RTOS , Ambarella A5S88 DSP | |
| Image Sensor | 1/3'' 3.0 Megapixel CMOS Image sensor. | ||
| Min. Illumination | [email protected] ( color), 0.001 [email protected] (B/W) | ||
| Lens / Fill Light | Lens optional 4mm\6mm | ||
| Day & Night | IR cut filter with auto switch | ||
| Image Output | Main Stream: 2048×1536,1920×1080,1600×1200,1280×1024,1280×960,1024×768,1280×720 / Sub Stream: 640×360,480×270,352×288,320×240,352×192,320×192,288×192,256×192 |
||
| Frame Rate | 3.0 Megapixel@17FPS, 2.0 Megapixel@25FPS | ||
| Compression Standard | Video Processing | H.264 video coding support dual-stream, AVI format,Main Profile | |
| Dual Stream | Yes | ||
| Bit Rate | 0.1M-6Mpbs | ||
| System Compatibility | ONVIF Ver. 2.0 | ||
| Network Function | Alarm Trigger: | Motion detection | |
| Protocols | RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP | ||
| Smart Phone | iPhone, iPad, Android | ||
| Interface | Communication Interface: | 1 RJ45 10M / 100M ethernet interface | |
| Others | Operating Conditions | -30 °C ~ 60 °C (-22 °F ~ 140 °F) | |
| Power Supply | 12V DC | 12V DC/ PoE (802.3af) | |
| Power Consumption | |||
| IR Light | 24x Φ5 LED | ||
| IR Distance | EXIR: 20 M |
||
