DVB-T Antenna

Working Voltage 5V
Working current 10mA40mA
Working frequency VHF-H174MHz240MHz
UHF470MHz862MHz
Input gain 18±3dB
Output Impedance 75Ω
V.S.W.R: 2.0:1
Noise 3dBm

FM/AM Antenna

Frequency: AM 525Mhz~1610Mhz
FM 76Mhz~108Mhz
V.S.W.R. < 1:1.5
Impendencen 75 Ohm
Polarization none
Max gain >8db

Working Temp -20'C~+70'C
Humidity 95%~100%RH
Vibration none
Waterproof 100% Waterproof

Connector SMA/SMB/MCX/MMCX/BNC/FME
Amplifier Specification
LNA Gain AM -2db~-6db
FM +8db~+12db
Noise Figure 1.5db
V.S.W.R. <2.1
DC Voltage DC 10.5V~15V
DC current 30mA~65 mA
