1.Specifications:

\r\n

* Frequency response: 20Hz-20KHz
\r\n* Separation: >= 50dB
\r\n* Operating current: 50mA
\r\n* stand-by current: 90uA
\r\n* Transmission rang: 88.0-108.0MHz (interval0.1MHz)
\r\n* Power source: car power source
\r\n* Connecting cord length: 1.20m
\r\n* Dimentsions: D104.2 x W78.3 x H31.8mm
\r\n* N.W: 68g
\r\n* G.W: 130g

\r\n

2.How to use

\r\n

* Connect to the car's power source.
\r\n* Plug the Audio jack of FM Transmitter into the audiio device's output port.
\r\n* Adjust the volume and frequency of the FM radio (avoid the transmission points of the broadcasting stations).
\r\n* Press the power button of the FM Transmitter, tune the transmission frequency according to the reception frequency of the FM radio.
\r\n* If the FM signal is interrupted, please set the frequency of the FM Transmitter and the FM tuner to the other frequency.
\r\n* Press M1/M2/M3/M4 button for a few seconds until M1/M2/M3/M4 is shown on the LCD, so that you can save the transmission frequency.
\r\n* The FM Transmitter will automatically shut down if no audio frequency is input.

\r\n

3.Features:

\r\n

* High fidelity, stereo
\r\n* This device can modulate the audio signal of (Portable CD,MD,MP3,Notebook??Mp4,PC etc. Need customized connectors??and the iopd to FM signal(88.0-108.0MHz)whth the stereo tune you can enjoy listening high quality music anywhere.
\r\n* Digital PLL
\r\nWith digital PLL,w ave signal transmission and reception with not be affected even in places subject to extreme charger in temperature.In additiion,using the digital tune can avoid the fussy frepuency modulation.
\r\n* Powered by the car's power source.
\r\n* Full frequency range design can effectively avoid interruptiion.

\r\n

4.Note:

\r\n

*Because of the transmission the FM signal may sometimes be interrupted.

\r\n

*The specification may change when we improve this product then we ton't give other notice.
