Application:

High quality and availability of energy adapted to suit specific critical needs,covering a vast range of applications.

Typical Application:

Home PCs ,Workstations,Audio/Video Equipment(TVs,DVD players,Sound systems),Entertainment systems, Other electronic equipments, Small electric domestics.

Manual Main Features:

Automatic Voltage Regulator

Automatically changes and corrects the output voltage, carefully following the input voltage

Visual indicators using 4 LEDS(Power/AVR/Surg/Overload)

Provides the user with the AVR functions status

Protects telephone,Internet,DSL,and Fax/Modem

120VAC or 220VAC(depending on the model)

6 NEMA standard outlets

Specifications:

MODEL		EVS-500	EVS-800	EVS-1200
CAPACITY		500VA	800VA	1200VA
INPUT
Voltage	Nominal Voltage	110/115/120VAC or 220/230/240 VAC
	Acceptable Voltage Range	80VAC~144VAC or 161VAC~288VAC(-30%,+25%)
Phase		1 Phase 2 Wires
Frequency		50Hz or 60Hz
OUTPUT
Output Voltage Range		103VAC~127VAC or 207VAC~253VAC(±-10%)
Frequency		50Hz or 60Hz
PROTECTION
Network Surge Suppression		RJ-11
Overload Protection		Manual Reset Circuit Switch
Short circuit Protection		Manual Reset Circuit Switch
INDICATORS
Power LED On/Off		Green lighting
Output Cut Off LED		Red lighting
PHYSICAL
Dimension, D X W X H (mm) (@ vertically stand)		215*115*90mm
Net Weight (kgs)		1.8	2.0	2.55
OUTLETS
AVR		6 Nema / 4 Schuko
OPERATING ENVIRONMENT
Humidity		0-95%(non-condensing)
Operating Temperature		0~40°C
Noise Level		Less than 40dB at 1M
. Different specifications required are available. . All specifications mentioned above are subject to change without prior notice.
