Catelogue: Solar AC Home Systems
Hits:
• Zero pollution
• Environmental friendly
• All-in-one system
• Easy to install and remove
The off-grid AC solar power system (SAC series) consists of solar panels, controller, battery and inverter. This system is designed to supply independent DC and AC power to civil and commercial application with both DC 5V/12V and AC 110V/220V output. It can be used for house hold appliances and equipments, such as computers, TV, fridges, etc. in remote areas or regions where there is no electricity supply. It can be also used for camping, outdoor working and emergency power supply, etc.
Specification
| Model number | SAC-C-300W/A |
| Rated power | 300W |
| Solar panel | 30W(15W×2pcs) monocrystalline |
| Battery | 12V18Ah AGM DC battery |
| The maximum continuous output power | 200Wh |
| Recommended output power per day | 120Wh |
| Continuous working time | 40mins at 300W output (approx.) |
| Electricity charging function | yes |
| Light source | 3pcs DC 12V2W LED lamp |
| Luminous flux | 60±5 lm/w |
| The Maximum continuous working hour | 33 hours (3pcs lamp); 100 hours (1pc lamp) |
| Recommended working hour per day | 20 hours (3pcs lamp); 60 hours (1pc lamp) |
| Charging time | 10 hours |
| Output voltage | DC 5V/12V; AC 110V or 220V 50～60Hz |
| Precision of output voltage | 3% |
| Output waveform | Pure sine wave |
| Ambient temperature | -10℃～45℃ |
| Relative humidity | 0～85%RH |
| Operating altitude | 0～2500m |
| Size of host case(mm) | 430×430×190 |
| Weight of host case | 14.6kgs |
Specification
| Model number | SAC-C-300W/B |
| Rated power | 300W |
| Solar panel | 40W(20W×2pcs) monocrystalline |
| Battery | 12V22Ah AGM DC battery |
| The maximum continuous output power | 260Wh |
| Recommended output power per day | 150Wh |
| Continuous working time | 50mins at 300W output (approx.) |
| Electricity charging function | yes |
| Light source | 3pcs DC 12V2W LED lamp |
| Luminous flux | 60±5 lm/w |
| The Maximum continuous working hour | 43 hours (3pcs lamp); 130 hours (1pc lamp) |
| Recommended working hour per day | 25 hours (3pcs lamp); 75 hours (1pc lamp) |
| Charging time | 9 hours |
| Output voltage | DC 5V/12V; AC 110V or 220V 50～60Hz |
| Precision of output voltage | 3% |
| Output waveform | Pure sine wave |
| Ambient temperature | -10℃～45℃ |
| Relative humidity | 0～85%RH |
| Operating altitude | 0～2500m |
| Size of host case(mm) | 470×430×190 |
| Weight of host case | 17.5kgs |
