Picture of 4+1 ports POE switch IEEE802.3af standard, 15.4W

4+1 ports POE switch IEEE802.3af standard, 15.4W

SKU: FS00040054
4+1 ports POE switch IEEE802.3af standard, 15.4W
Reproduction is welcome and allowed for free circulation only.


Power over Ethernet is a technology which eliminates the need to run 100~240V AC Power to devices such as Wireless AP, IP cameras, VoIP and other devices on a wired LAN. Using Power over Ethernet system, enable installers to run only on a single Cat.5 Ethernet cable that carries both power and data to each individual networking device. This allows greater flexibility in the locating of AP’s, network device and will significantly decrease the installation costs in cases involving system integrations.

SW-105P10/100M Desktop PoE Switch provides the seamless network connection. It integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities. For cost saving and flexible using of PoE power provision, SW-105Pprovides PoE power injector function which is able to drive 4 IEEE 802.3af compliant powered devices. Besides, the switch also provides a simple, cost-effective, and highly reliable network connection for data as well as power. SW-105PPoE switch provides power and data from a single point, using power over ethernet(PoE) over a single cat-5 cable.

Power over Ethernet is a technology which eliminates the need to run 100~240V AC Power to devices such as Wireless AP, IP cameras, VoIP and other devices on a wired LAN. Using Power over Ethernet system, enable installers to run only on a single Cat.5 Ethernet cable that carries both power and data to each individual networking device. This allows greater flexibility in the locating of AP’s, network device and will significantly decrease the installation costs in cases involving system integrations.

SW-105P10/100M Desktop PoE Switch provides the seamless network connection. It integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities. For cost saving and flexible using of PoE power provision, SW-105Pprovides PoE power injector function which is able to drive 4 IEEE

Technical Spec

Input Voltage

48V DC

Network standards

IEEE802.3i 10 BASE-T,

IEEE802.3u 100 BASE-TX,

IEEE802.3x flow control

IEEE802.3af / IEEE802.3at

PoE power

15.4W per port

Wiring: Data & Power provided over pairs 12&36 and 45(+) & 78(-)

Cable: UTP cat.5 or higher

Processing types

Store-and-forward

Half-duplex back pressure and IEEE802.3x full-duplex flow control

Power supply

Total power consumption: 70W

Total PoE power budget: 60W

Performance spec

Bandwidth: 1.6Gbps

Network delay(100 to100M bps):less than 2ms

Buffer Memory:96KB

Address Database Size: 1000MAC/system

LED indicator

System: Power,PoE max

per port: speed, link,,PoE active, PoE failure

Environment Criterion

work temperature: 0℃-50℃

work humidity: 10% 90%, no condensation

Electromagnetism compatibility

CE Class B

FCC Part 15, Class B

VCCI Class B

C-Tick

Product Size:

140*91*28 mm

Authenticate

CE/FCC/RoHS

Warranty

One year

Gross Weight

0.85kg

802.3af compliant powered devices. Besides, the switch also provides a simple, cost-effective, and highly reliable network connection for data as well as power. SW-105PPoE switch provides power and data from a single point, using power over ethernet(PoE) over a single cat-5 cable.

Easy Cabling Installation:

With data and power over Ethernet from one unit, the SW-105Pshall reduce cables and eliminates the need for dedicated electrical outlets on the wall, ceiling or any unreachable place. A wire carries both data and power lowering the installation costs, simplifying the installation effort and eliminating the need for electricians or extension cords. It is a great selection for expanding your home or office network.

Features:

* Standard compliant IEEE802.3af
* Support 10/100Mbps fast Ethernet
* Data transmission up to 100 meters
* Support power up to 15.4W per each port
* LED indicators show working status of LAN and power
* Anti-Static and Circuit Isolation protection via Anti-Lighting Chip design
* Easy installation and use , no need to convert by software and network protocol
