Picture of Disconnection Module

Disconnection Module

SKU: FS00040352
Disconnection Module
Reproduction is welcome and allowed for free circulation only.


Product Name : 10 Pair Profile Hihgband Disconnection Module , Snop Onto 95mm Profile Rods
Model : MG-2075
1.Environment condition: -5-40 degree Celsius ;Relative humidity <85% (+30 degree Celsius);Atmospheric pressure: 70-106KPa ;
2.The modules are compatible with KRONE LSA-PLUS modules. The design of contacts basing on the principle of airtight contacting makes a completely reliable connection between the contacts and wires
3.Pulling-out force: tin bronze and silver plating (20-40 uinch), pulling-out force not less than 25N ;
4.Internal diameter of connection wire: 0.4-0.6 mm
5.The performance of anti-burn: PBT (UL94V-0)or anti-burn ABS (UL94V-0),Combustibility achieved GB/T 5169.7-1985 standard ;
6.Insulated resistance: under standard atmospheric pressure ,Insulated resistance no less than 1,000M ohm between the two disjunct connections ;
7.Intermediate resistance between the reed terminators: no more than 7m ohm between intermediate reed under the standard examination condition ;
8.Intermediate resistance: no more than 3m ohm under standard examination condition ;
9.Dielectric strength: according to industry standard
10.Specification:8 pairs
11.Type: disconnection types
12.insertion Life: durability 200 cycles
13.OEM
14.Package : we can do as your request
