DVB-C/T TV Receiver I2C-bus Full Band Tuner

FEATURES

• Full frequency range from 51 to 860MHz for DVB-C /T
• Low IF tuner concept
• Programmable channel Filter bandwidth
• Active LT & single supply voltage
• Fully I2C bus controlled

 The half-NIM includes a full band tuner, an antenna loop through function (Active) and channel filtering for digital signals. It provides a low IF output after channel filtering to drive a DVB-C /T demodulator. Tuning, band switching and initialization are made via an I2C bus interface. The module is built on a low-loss printed circuit board carrying all the components in a metal housing frame with top and rear covers. The 2 aerial connectors are mounted on one frame side all other connections are made via pins at the bottom

NO

SPECIFICATION

3



RATINGS

Environmental conditions

SYMBOL

PARAMETER

CONDITIONS

MIN

MAX

UNIT

Non-operational Conditions

TAMB

RH

Ambient temperature

Relative humidity



-25

-

+85

-

°C

%

GB

Bump acceleration

25g

-

245

m/s2

GS

Shock acceleration

50g

-

490

m/s2







-



mm

Operational conditions

TAMB

RH

Ambient temperature



-10

-

+60

95

°C

Relative humidity

%



Limiting values under operational conditions

The tuner can be guaranteed to function properly under the following conditions.

SYMBOL

PARAMETER

PIN

MIN

TYP

MAX

UNIT

VTU

ITU

Tunet supply voltage

Relevant supply current

3

3.13

3.3

3.47

V

-



270

mA

VIF-AGC

IF-AGC input voltage

7

-

3.0

3.47

V

VIF-AGC

IF-AGC input voltage range

0

-

3.0

V

lIF-AGC

IF-AGC input current

-

-

10

μA

VSCL

Serial clock input voltage

4

-0.3

-

3.47

V

VSDA

Serial data input voltage

5

-0.3

-

3.47

V

ISDA

Serial data input current

-1

-

5

mA

4



SPECIFICATION DATA

If not otherwise stated the electrical performance refers to:

1.ambient temperature               :22°C±2°C

2.relative humidity                  :60%±10%

3.supply voltages                   :3.3V±0.1V

4.IF-gain control voltage             :1V max

5.RF-input termination               :75ohms

6.RF-output termination              :75ohms

No

Parameter

Conditions

Min

Typ

Max

Unit

Remarks

1.

Frequency range

DVB-C

51

-

860

MHz

Refer to channel

center frequency

2.

IF frequency



3

-

5

MHz

Depending on channel bandwidth

3.

IF output level



-

1

-

Vp-p

differential

4.

Channel bandwidth



6

-

8

MHz

programmable

5.

Image rejection



50

-

-

dB



6.

Return loss

Antenna In

8

-

-

dB

RF_OUT terminated with 75 Ω

7.

Noise figure



-

6.5

9.0

dB

 (TBD)

8.

Voltage Gain

Ant IN to DIF Out

-

71

-

dB

(TBD)

9.

IF AGC range



-25

-30

-

dB



10.

Oscillator stability



-

25

-

ppm



11.

Oscillator phase noise

At 1KHz

At 10 kHz

At 100 k



-

-

-80

-85

-105

dBc/Hz



12.

Acquisition time



-

5

-

ms



13.

Start up time



-

-

1500

ms



14.

Antenna Leakage



-

-

46

dBuV

At 75Ω, EN55013

15.

CSO

Ant IN to DIF Out

-

-52

-48

dBc

(TBD)

16.

CTB

Ant IN to DIF

Out

-

-52

-48

dBc

(TBD)

17

Outer band attenuation

At 45MHz

16.5





dB



At 30MHz

23.5





dB



At 16.38MHz

42.0





dB



At 10MHz

45.0





dB



5



Antenna Active Loop through (TBD)

No

Parameter

Conditions

Min

Typ

Max

Unit

1.

Frequency range



51

-

860

MHz

2.

Return loss at TV out



6.0

-

-

dB

3.

Power gain at TV out

51 – 500MHz

500—860MHz

-1.0

-3.0

1.0

0.5

-

-

dB

4.

Noise figure at TV out



-

7.5

9.0

dB

5.

Oscillator leakage at  <300 MHz

TV out             >300 MHz



Antenna Input terminated with 75Ω

-

-

15

26

dBμV

dBμV

6.

Linearity at TV out

CSO

CTB



-

-

-

-

- 50

- 50



dBc





6



MECHANICAL DIMENSIONS

General tolerances±0.5mm unless otherwise stated/all dimensions in millimeter/drawings not to scale

Pin

Function

Description

1.

ANT VCC

NC

2.

--

NC

3.

VCC1

+3.3 Volt nominal

4.

SDA

I2C bus data

5.

SCL

I2C bus clock

6.

CLK_OUT

Crystal buffer output

7.

IF_AGC

IF AGC input

8.

IF_N

Digital IF output 1

9.

IF_P

Digital IF output 2

7.Application Information

The module contains of one programmable part, the tuner IC TDA18250HN, which can directly be programmed by the I2C-bus

7.1  Tuner

The source code for the TDA18250HN will be provided on request.

7.2  I2C Bus Requirements

The I2C implementation in the TDA18250HN follows the I2C bus specification, version 2.1, January 2000 as edited by Philips Semiconductors

7.3   I2C chip addresses

Write address: 0xC0, Read address: 0xC1

8.    Electrostatic Discharge

8.1   Test

Each device must be capable of normal performance following its subjection to the following tests:

 MIL STD 883C HBM

Test is performed with a voltage discharge from a 100 PF capacitor over a 1500 Ω series resistance in the discharge path. There is a direct contact between the test probe head and the unit under test, using the test points and conditions detailed below:

• Test to pins 1 through last pin : 3 successive ESD discharges of  2 KVDC between each pin and the

device frame.

IEC 1000-4-2

Test is performed with a voltage discharge from a 150 PF capacitor over a 330 Ω series resistance in the discharge path. There is a direct contact between the test probe head and the unit under test, using the test points and conditions detailed below:

•Test for antenna input socket  8 KVDC

•Test for antenna output socket  5 KVDC

8.2 Handling

Anyone handling a device must wear a properly grounded anti - static discharge bracelet to minimize ESD damage.

After each device is aligned and tested, it will be packed with anti - static poly-foam or material prior to transportation and storage. This protective foam is to remain in place until the device is assembled and soldered onto the receiver main board



9. Reliability Test Procedure & Conditions

Note: Room temperature = 25 °C ± 2 °C

9.1Heat Load Test

• Measure the DUTs at room temperature

•Load the DUTs into chamber of the following conditions:

 Temperature = 60 °C

Period = 500 hrs

Cycle = 1,5 hrs on; 0,5 hrs off

Quantity = 10 pcs

•Cool-down 0,5 hr at room temperature, then perform functional test on DUTs within 1hr

•The test shall be continued to 1000 cycles for information only ( Optional )

9.2 Humidity Load Test

•Measure the DUTs at room temperature

• Load the DUTs into chamber of the following conditions:

Temperature = 40  5 °C

Period = 24 hrs

Cycle = constantly on

Quantity = 20 pcs

•Cool-down 0.5 hr at room temperature, then perform functional test on DUTs within 1hr

• Load the DUTs again into chamber of the following conditions:

 Temperature = 40  5 °C

Humidity = 90 to 95 %

Period = 500 hrs

Cycle = 1,5 hrs on; 0,5 hrs off

Quantity = 20 pcs

•Cool down 0.5 hr at room temperature, then perform functional test on DUTs within 1hr

9.3Cold Test

•Measure the DUTs at room temperature

• Load the DUTs into chamber of the following conditions:

 Temperature = - 20  5°C

Period = 500 hrs

Cycle = constantly on

Quantity = 10 pcs

•Warm up for 2 hrs at room temperature, then perform functional test on DUTs within 1hr



9.4Thermal Shock

•Measure the DUTs at room temperature

• Load the DUTs into chamber of the following conditions:

 Temperature = - 25 °C for 60 min

 ↓ ↑

                  85 °C for 60 min

Period = 200 cycles

Power = power off

Quantity = 10 pcs

•Cool-down 0,5 hr at room temperature then perform functional test on DUTs within 1hr

9.5 Temperature Cycle Test

• Measure the DUTs at room temperature

• Load the DUTs into chamber of the following conditions:

 Temperature = -5 °C for 16 hrs then 60°C for 8 hrs

Period = 500 hrs

Cycle = constantly on

Quantity = 10 pcs

•Cool down 0.5 hr at room temperature, then perform functional test on DUTs within 1hr

9.6Vibration Test

•Frequency:  3,5 Hz

• Vertical amplitude: 15 to 25 mm

•Duration:  1 hr

•Quantity:  1 carton

9.7Drop Test

•Packaged apparatus: < or = 50 kg

•Height: 32 … 50Kg: 0.5m

  18 … 32Kg: 0.55m

10 … 18Kg: 0.65m

  5 … 10Kg:  0.8m

•1 corner + 3 edges + 6 faces

•Quantity: 1 carton

9.8 Life Test

•Measure the DUTs at room temperature

• Load the DUTs into chamber of the following conditions:

 Temperature = 60°C

Period = 500 hrs

Cycle = constantly on

Quantity = 20 pcs

•Cool down 0.5 hr at room temperature, then perform functional test on DUTs within 1hr
